YATTLL Portable Power Wheelchair With Brushed Motor - Camel Hope YE246

YATTLL Portable Power Wheelchair With Brushed Motor - Camel Hope YE246

Camel Hope YE246 is made of aircraft level aluminum material. It is our first innovation which putting brushed motor on such a lightweight and simple designed power wheelchair. Huge improvements made on the innovated structure, appearance and product quality. Mean While, the competitive price let more passengers affordable for this unique wheelchair.

Technical Information of Portable Power Wheelchair With Brushed Motor Camel Hope YE246

parameter
Item No. :CAMEL HOPE YE246
Dimension (Unfolded):104*62*98 cm / 41*24.4*38.6 in
Dimension (Folded):80*62*34 cm / 31.4*24.4*13.3 in
Seat Width:45 cm / 17.7 in
Seat Depth:43 cm / 17 in
Backrest Height:53 cm / 20.8 in
Floor-to-Seat Height:50 cm / 19.6 in
Frame:Lightweight Aircraft Quality Aluminum
Seat & Backrest:Breathable durable seat cushion & pocket removable for easy clean
Controller:Compatible with most Brush motor PG controller availablCompatible with most Brush motor PG controller available
Motors (pair):BLDC Brush motor 250W *2 pcs
Batteries:Lithium Battery 24V 11AH
Max Speed:8 km/h / 5 miles/h
Charger:High Power 2A
Charging Hour:6 Hours
Brake:Electromagnetic Bracking system Change Power mode to manual model freely
Armrest:Flip up armrest to excess in and out freely
Legrest:Foldable legrest to let passengers be closer & safer to sit on the chair
Rear Wheel:12.5" rear wheel with suspension
Caster:8″ Solid front wheel
Maximum Range:10-13 km / 6.2-8 miles
Weight Capacity:135KG / 300 lbs
Ground Clearance:8 cm / 3 in
Max Slope:12 degrees
Net Weight:Without Battery 24.65 kg / 54 lbs
Net Weight:Including Battery 26.5 kg / 58.4 lbs
WARRANTY:
frame:3 Years
Controller:12 Months
Motor:12 Months
Batteries:12 Months


YATTLL Portable Power Wheelchair With Brushed Motor Camel Hope YE246 Gif Display

Portable Power Wheelchair With Brushed Motor Camel Hope YE246 Video

Portable Power Wheelchair With Brushed Motor Camel Hope YE246 Video

Videos
Portable Power Wheelchair With Brushed Motor Camel Hope YE246 Video
Portable Power Wheelchair With Brushed Motor Camel Hope YE246 Video

Features/Characteristics of Portable Power Wheelchair With Brushed Motor Camel Hope YE246

Features
01
Weighs 24.65kg without battery and supports passengers weighing up to 135kg.
02
The compact Camel Hope wheelchair Folds in 1 second for effortless transport.
03
With a folded size 80*62*34cm Camel Hope is much more compact than its competitors.
04
It can easily fit in the trunk of most Vehicles for travel.
05
With its 12.5" rear wheel and 8" front wheel Camel Hope has a high Ground clearance ability.
06
Compatible with most Brush Joysticks on market and the Joystick can be mounted on left or right side of Armrest.
07
With a seat width of 45cm and backrest height of 53cm Camel Hope offers large space for passengers and gives super comfortable experience during daily activities.
08
The foldable legrest makes passengers be closer and safer when they are going to sit on the chair.
09
Lithium-ion battery can travel up to 15 km.
10
Removable seat cushion and durable pocket for easy cleaning.
